Victron Phoenix Inverter - 12 VDC - 3000W - 120 VAC - 50/60Hz

No reviews yet Write a Review
$1,269.73
SKU:
PIN123020100
UPC:
8719076023586
Condition:
New
5 customers are viewing this product

Victron Phoenix Inverter - 12 VDC - 3000W - 120 VAC - 50/60Hz

$1,269.73

Victron Phoenix Inverter - 12 VDC - 3000W - 120 VAC - 50/60Hz Product Description

Phoenix Inverter - 12 VDC - 3000W - 120 VAC - 50/60Hz

Pure sine wave output, high peak power and high efficiency. Combined high frequency and line frequency technologies ensure the best of both worlds.

SinusMax - Superior engineering

Developed for professional duty, the Phoenix range of inverters is suitable for the widest range of applications. The design criteria have been to produce a true sine wave inverter with optimised efficiency but without compromise in performance. Employing hybrid HF technology, the result is a top quality product with compact dimensions, light in weight and capable of supplying power, problem free, to any load.

Extra start-up power

A unique feature of the SinusMax technology is very high start-up power. Conventional high frequency technology does not offer such extreme performance. Phoenix inverters, however, are well suited to power up difficult loads such as refrigeration compressors, electric motors and similar appliances.

Parallel and 3-phase operation capability

Up to 6 Phoenix Inverters can operate in parallel to achieve higher power output. Six 24V 5000VA units, for example, will provide 24kW / 30kVA output power. Operation in 3-phase configuration is also possible.

Communications interface

These larger Phoenix inverter models come with a VE.Bus port. All you need to connect to your PC is our MK3-USB VE.Bus to USB interface (see under accessories). Together with our VictronConnect or VEConfigure software,  which can be downloaded free of charge from our website, parameters of the inverters can be customized. This includes output voltage and frequency, over and under voltage settings and programming the relay. This relay can for example be used to signal several alarm conditions, or to start a generator. The inverters can also be connected to a GX device (eg Cerbo GX) for monitoring and control.

"Warning"WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to .

Please contact your dealer for any returns, repairs or support issues related to this product.

It is built on our proven Phoenix inverter platform and now has a new ultra-thin design and an all-metal housing. The models suitable for 12, 24 or 48V systems are 1600VA, 2000VA and 3000VA. It is powerful enough to provide the most common plug-in equipment for your car, boat, caravan or home. Toroidal transformers can provide high peak power surge capability, stable voltage, frequency and high-quality sine waves. Installation is simpler than ever, and installers can now access the terminal more easily, enabling a more professional decoration. Bluetooth is built-in, making it easier than ever to set up a high-power inverter. Configure alarms, alarm relays, voltage cutoff, output voltage, frequency, energy saving mode, etc. in VictronConnect.













Frequently Asked Questions (FAQ) About Victron Phoenix Inverter - 12 VDC - 3000W - 120 VAC - 50/60Hz











Who is the Victron Energy?

Victron Energy is a global company with a reputation for technical innovation, reliability, and build quality. Victron products, which excel at efficiently combining two or more distinct power sources, are recognized internationally as the professional choice for resilient energy storage systems. Victron products include sinewave inverters, sinewave inverters/chargers, battery chargers, DC/DC converters, transfer switches, battery monitors and more.

How to describe Victron Phoenix Inverter - 12 VDC - 3000W - 120 VAC - 50/60Hz?

It is built on our proven Phoenix inverter platform and now has a new ultra-thin design and an all-metal housing. The models suitable for 12, 24 or 48V systems are 1600VA, 2000VA and 3000VA. It is powerful enough to provide the most common plug-in equipment for your car, boat, caravan or home. Toroidal transformers can provide high peak power surge capability, stable voltage, frequency and high-quality sine waves. Installation is simpler than ever, and installers can now access the terminal more easily, enabling a more professional decoration. Bluetooth is built-in, making it easier than ever to set up a high-power inverter. Configure alarms, alarm relays, voltage cutoff, output voltage, frequency, energy saving mode, etc. in VictronConnect.
  • The Phoenix Inverter is a 12 VDC, 3000W inverter that provides 120 VAC at 50/60Hz.
  • It has a SinusMax technology that combines high frequency and line frequency technologies for the best of both worlds.
  • Phoenix Inverter - 12 VDC - 3000W - 120 VAC - 50/60Hz Pure sine wave output, high peak power and high efficiency. Combined high frequency and line frequency technologies ensure the best of both worlds. SinusMax - Superior engineering Developed for
  • The Phoenix inverter has a 3-year warranty and a 5-year warranty on parts.
  • The SinusMax is designed to be energy efficient and can be used in any country with voltage ranging from 110V to 240V.
  • Phoenix inverters are designed to power the world's most demanding applications.
  • The SinusMax technology ensures the best of both worlds - high efficiency and high frequency.
  • Phoenix inverters are optimized to provide a pure sine wave output, which is necessary for sensitive loads such as medical equipment, computers, and other electronics.

How many outlet exists on this product?

None
  • The Phoenix Inverter is a 12 VDC, 3000W inverter that provides 120 VAC at 50/60Hz.
  • It has a SinusMax technology that combines high frequency and line frequency technologies for the best of both worlds.
  • Phoenix Inverter - 12 VDC - 3000W - 120 VAC - 50/60Hz Pure sine wave output, high peak power and high efficiency. Combined high frequency and line frequency technologies ensure the best of both worlds. SinusMax - Superior engineering Developed for
  • The Phoenix inverter has a 3-year warranty and a 5-year warranty on parts.
  • The SinusMax is designed to be energy efficient and can be used in any country with voltage ranging from 110V to 240V.
  • Phoenix inverters are designed to power the world's most demanding applications.
  • The SinusMax technology ensures the best of both worlds - high efficiency and high frequency.
  • Phoenix inverters are optimized to provide a pure sine wave output, which is necessary for sensitive loads such as medical equipment, computers, and other electronics.

What is the AC connection of the Victron Phoenix Inverter - 12 VDC - 3000W - 120 VAC - 50/60Hz?

Hardwire

What is the output voltage?

3000w

What is the input voltage?

10-17v

What is the output voltage?

120v

Is this product has ground-fault circuit interrupter (GFCI) feature?

No

What is the inverter surge rating of the product?

6000w

What is the waveform of the product?

Pure Sine Wave


Save $203 when you buy the Victron Phoenix Inverter - 12 VDC - 3000W - 120 VAC - 50/60Hz for only $1154 from NVN Marine! Same day fast and free shipping before 3pm.

Victron Phoenix Inverter - 12 VDC - 3000W - 120 VAC - 50/60Hz Technical Specifications

Type:

Vendor:

Victron Energy

Weight:

47.1 lb

Waveform:

Pure Sine Wave

Inverter Surge Rating:

6000w

Inverter Output Voltage:

120v

Inverter Input Voltage:

10-17v

GFCI:

No

DC Connection Type:

Hardwire

AC Connection Type:

Hardwire

Outlet Qty:

None

Inverter Cont. Output Wattage:

3000w
