NewMar 12-24-7 DC Power Converter12 VDC to 24 VDC Non-Isolated Step-Up Converter, 7 Amp These "UP" converters produce 24 volts from 12 volt systems and are ideal for managing dual voltage applications on vessels and vehicles without having to install a 24 volt battery and dedicated charging system. In the Standard, Non-Isolated Series the 12V input and 24V output share a common negative ground and are ideal when installing certain electronics that operate better on 24 volts when a robust 12 volt system exists
These "UP" converters produce 24 volts from 12 volt systems and are ideal for managing dual voltage applications on marine vessels without having to install a 24 volt battery and dedicated charging system. Choose from two types depending on your application:
In the Standard, Non-Isolated Series the 12V input and 24V output share a common negative ground and are ideal when installing certain electronics that operate better on 24 volts when a robust 12 volt system exists. Models available in outputs of 7, 16 and 25 amps.
Model | Input voltage | Output voltage | Output Amps Intermittent | Output Amps Continuous | Case Size | Weight | |
Lbs | Kg | ||||||
Standard - Non-Isolated | |||||||
12-24-7 | 10-15 | 27.2 | 7 | 7 | C-1 | 1.4 | .64 |
12-24-16 | 10-15 | 27.2 | 16 | 16 | C-2 | 3.55 | 1.61 |
12-24-25 | 10-15 | 27.2 | 25 | 25 | C-3 | 4.1 | 1.86 |
Case | Inches | Centimeters | ||||
H | W | D | H | W | D | |
C-1 | 3.5 | 3.5 | 1.75 | 8.9 | 8.9 | 4.5 |
C-2 | 4.25 | 5.9 | 14.0 | 10.8 | 15.0 | 35.6 |
C-3 | 6.0 | 6.8 | 16.5 | 15.2 | 17.3 | 41.9 |
Input: 10 - 15V DC
Output: 27.2 VDC +/-5% at extreme temperature load, input, tolerance, etc.
Ripple: <100mV P-P
Regulation: +/- 5% Line/Load
Duty Cycle:
Intermittent: 2 minutes, 20% duty
Continuous: 24 hours, 100% duty
Operating Temp: -25? - 30? C, derate linearly from 30 to 0% @ 80? C
MechanicalType: | |
---|---|
Vendor: |
NewMar |
Weight: |
3.0 lb |
