Lewmar V2G Vertical Windlass Gypsy Only Kit 002 12v 5/16 G4 Chain 1/2 Line

No reviews yet Write a Review
$3,680.40
SKU:
6672011108-138
UPC:
743683328015
Condition:
New
5 customers are viewing this product

Lewmar V2G Vertical Windlass Gypsy Only Kit 002 12v 5/16 G4 Chain 1/2 Line

$3,680.40

Lewmar V2G Vertical Windlass Gypsy Only Kit 002 12v 5/16 G4 Chain 1/2 Line Product Description

The V Series represents the pinnacle of Lewmar's windlass development. Robust stainless steel deck units combined with powerful motors, the V Series is capable of withstanding the toughest conditions. Designed as the ideal anchoring companion for all serious boaters, the V Series windlasses are strong, beautiful and dependable.

Lewmar 2011108138 Attributes

  • Mount Type: Vertical
  • Maximum Pull: 1874 Pound
  • Working Load Limit: 470 Pound
  • Maximum Line Speed: 69 Feet Per Minute
  • Size: 8-3/4 Inch Width X 6-5/8 Inch Height
  • Chain/ Rope Size: 002 To 10 Millimeter DIN 766/ Campbell 3/8 Inch S4/ 5/16 Inch G40 Chain
  • Material: Stainless Steel
  • Ampere Rating: 80 Amp
  • Voltage Rating: 12 Volt
  • Motor Power: 700 Watt

Lewmar 2011108138 Features & Benefits

  • Rope-Chain Gypsy
  • Cone Clutch For Smooth, Easy Control
  • Optional Manual Override Motor Gearbox
  • W.A.R.P Drum
  • Fall Safe Anchor Lock
  • Worm Gearbox
  • Limited 3 Year Warranty

Lewmar 2011108138 Warranties

Lewmar 2011108138 Technical Bulletins


Lewmar V2 Gypsy Only Capstan Windlass with 002 Kit

Model: 6672011108-138
  • Rope-chain gypsy
  • Manual chain release (Free Fall)
  • Cone clutch for smooth, easy control
  • Fall safe anchor lock
  • Robust/reliable worm gearbox
  • FastFit™ option for quicker installation and less hassle
  • Emergency recovery kit available

While the gearbox alignment to the deck unit is critical to a standard installation, the FastFit™ clamping system perfectly aligns the deck unit and motorgearbox for a perfect fit first time.

Specifications
Fits Chain 10mm DIN 766, Campbell 3/8" S4, 5/16" G40
Fits rope 12-16mm, 1/2- 5/8" 3-strand and 8-plait(5/8" Only)
Motor Power 700 watts
max pull 1433 lbs
Working Load 358 lbs
max line speed 69 ft/min
Normal curren draw 80 Amps
Circuit breaker 90 Amps

What's in the Box:
  • V2 Gypsy Only Deck Unit
  • V2 12V FF MG-BOX ASSY
  • Gaurded Rocker Switch
  • V2 GYPSY/STR KIT 002
  • CIRCUIT BREAKER 90 AMP
  • 12V Contactor 68000318
  • Windlass X Handle


The world's first compact vertical stainless steel windlass for power and sailing. This beautifully shaped deck device hides a strong and reliable worm gear box and provides maximum strength and control. In addition, you can use rope chains or full-chain anchors at the push of a button. For boats of 9 to 12m, 30 to 40ft, 66910032-138 gypsy has only 5/16 inch g4 chain and 9/16 inch line gypsy kit 66910035-138 gypsy and drum v2, 5/16 inch g4 chain And / 16 inch line gypsy and drum kit includes: complete windlass, rocker switch, two-way contactor, circuit breaker and handle features chain lock gypsy manual override and chain release optional stylish stainless steel deck unit conical The clutch can realize a smooth, easy-to-control drive train-sturdy and reliable CE certification.

Frequently Asked Questions (FAQ) About Lewmar V2G Vertical Windlass Gypsy Only Kit 002 12v 5/16 G4 Chain 1/2 Line








Who is the DS18 Audio?

DS18 focuses on quality Pro Audio, Jeep Audio, Motorcycle Audio, and UTV/ATV high output audio for all to enjoy. Maintaining a tough and reliable product that will stand the test of time and still give loud, distortion-free, audio is what DS18 strives for most and what you buy into with DS18 products.

How to describe Lewmar V2G Vertical Windlass Gypsy Only Kit 002 12v 5/16 G4 Chain 1/2 Line?

The world's first compact vertical stainless steel windlass for power and sailing. This beautifully shaped deck device hides a strong and reliable worm gear box and provides maximum strength and control. In addition, you can use rope chains or full-chain anchors at the push of a button. For boats of 9 to 12m, 30 to 40ft, 66910032-138 gypsy has only 5/16 inch g4 chain and 9/16 inch line gypsy kit 66910035-138 gypsy and drum v2, 5/16 inch g4 chain And / 16 inch line gypsy and drum kit includes: complete windlass, rocker switch, two-way contactor, circuit breaker and handle features chain lock gypsy manual override and chain release optional stylish stainless steel deck unit conical The clutch can realize a smooth, easy-to-control drive train-sturdy and reliable CE certification.

What is the material of Lewmar V2G Vertical Windlass Gypsy Only Kit 002 12v 5/16 G4 Chain 1/2 Line?

Stainless Steel

What is the weight of the product?

40

What is the size?

8-3/4 Inch Width X 6-5/8 Inch Height

What is the mount type of the product?

Vertical

What is the watts of the product?

700


Save $2088 when you buy the Lewmar V2G Vertical Windlass Gypsy Only Kit 002 12v 5/16 G4 Chain 1/2 Line for only $2319 from NVN Marine! Same day free shipping before 3pm.

Lewmar V2G Vertical Windlass Gypsy Only Kit 002 12v 5/16 G4 Chain 1/2 Line Technical Specifications

Type:

Vendor:

Lewmar

Weight:

25.0 lb
